Cheating the schedule's exponential growth

The upper curve in Figure 3 is the COCOMO schedule; the lower one assumes we're building systems at the 20-KLoC/program productivity level. The schedule, and hence costs, grow linearly with increasing program size.

But how can we operate at these constant levels of productivity when programs exceed 20 KLoC? The answer: by partitioning! And by understanding the implications of Brook's Law and DeMarco and Lister's study. The data is stark: if we don't compartmentalize the project, divide it into small chunks that can be created by tiny teams working more or less in isolation, schedules will balloon exponentially.

Professionals look for ways to maximize their effectiveness. As professional software engineers we have a responsibility to find new partitioning schemes. Currently 70 to 80% of a product's development cost is consumed by the creation of code and that ratio is only likely to increase because firmware size doubles about every 10 months. Software will eventually strangle innovation without clever partitioning.

Academics drone endlessly about top-down decomposition (TDD), a tool long used for partitioning programs. Split your huge program into many independent modules; divide these modules into functions, and only then start cranking code.

TDD is the biggest scam ever perpetrated on the software community.

Though TDD is an important strategy that allows wise developers to divide code into manageable pieces, it's not the only tool we available for partitioning programs. TDD is merely one arrow in the quiver, never used to the exclusion of all else. We in the embedded systems industry have some tricks unavailable to IT programmers.

One way to keep productivity levels high—at, say, the 20-KLoC/program number—is to break the program up into a number of discrete entities, each no more than 20KLoC long. Encapsulate each piece of the program into its own processor.

That's right: add CPUs merely for the sake of accelerating the schedule and reducing engineering costs.

Sadly, most 21st-century embedded systems look an awful lot like mainframe computers of yore. A single CPU manages a disparate array of sensors, switches, communications links, PWMs, and more. Dozens of tasks handle many sorts of mostly unrelated activities. A hundred thousand lines of code all linked into a single executable enslaves dozens of programmers all making changes throughout a Byzantine structure no one completely comprehends. Of course development slows to a crawl.

Transistors are cheap. Developers are expensive.

Break the system into small parts, allocate one partition per CPU, and then use a small team to build each subsystem. Minimize interactions and communications between components and between the engineers.

Suppose the monolithic, single-CPU version of the product requires 100K lines of code. The COCOMO calculation gives a 1,403 man-month development schedule.

Segment the same project into four processors, assuming one has 50KLoC and the others 20KLoC each. Communication overhead requires a bit more code so we've added 10% to the 100-KLoC base figure. The schedule collapses to 909 man-months, or 65% of that required by the monolithic version.

Maybe the problem is quite orthogonal and divides neatly into many small chunks, none being particularly large. Five processors running 22 KLoC each will take 1,030 man-months, or 73% of the original, not-so-clever design.

Transistors are cheap—so why not get crazy and toss in lots of processors? One processor runs 20 KLoC and the other nine each run 10-KLoC programs. The resulting 724 man-month schedule is just half of the single-CPU approach. The product reaches consumers' hands twice as fast and development costs tumble. You're promoted and get one of those hot foreign company cars plus a slew of appreciating stock options. Being an engineer was never so good.
